A line graph showing weight measurements over time for thirty samples, with upper and lower control limits marked.

Alt text: A line graph showing weight measurements over time for thirty samples, with upper and lower control limits marked.

This description was generated by AI and has not been verified by a human. If you spot an error, please use the feedback link below.

  • The graph plots weight in grams on the vertical axis against sample number from one to thirty on the horizontal axis.
  • There are three dashed horizontal lines indicating control limits: the upper control limit (UCL) is set at \(204.06\) grams, the lower control limit (LCL) is set at \(195.96\) grams, and a center line is marked at \(200.1\) grams.
  • The plotted data points show fluctuations in weight across the thirty samples.
  • The weights generally fluctuate between approximately \(197\) grams and \(202\) grams.
  • Some individual data points are near the lower end of the observed range, such as the measurement at sample number \(1\) and sample number \(18\).
  • The weights appear to remain within the established control limits for all thirty samples shown on the graph.
